A768EB107M1ELAS036
Manufacturer
KEMET
Description
KEMET - A768EB107M1ELAS036 - Polymer Aluminium Electrolytic Capacitor, 100 F, 25 V, Radial Can - SMD, 0.036 ohm
Datasheet
DownloadProduct Attributes
Type
Type
Capacitance
Tolerance
Voltage - Rated
ESR (Equivalent Series Resistance)
Lifetime @ Temp.
Max Operating Temperature
Ratings
Applications
Ripple Current (AC)
Ripple Current @ High Frequency
Size / Dimension
Height - Seated (Max)
Surface Mount Land Size
Mounting Type
Case/Package
Description
Polymer
100 µF
±20%
25 V
36mOhm
2000 Hrs @ 125°C
-55°C ~ 125°C
AEC-Q200
Automotive
62.75 mA @ 120 Hz
1.255 A @ 100 kHz
0.248" Dia (6.30mm)
0.236" (6.00mm)
0.260" L x 0.260" W (6.60mm x 6.60mm)
Surface Mount
Radial, Can - SMD
₹66.80
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
10
₹41.45
₹414.50
25
₹41.50
₹1037.61
50
₹30.73
₹1536.29
100
₹27.33
₹2733.11
500
₹21.44
₹10720.14
1000
₹19.58
₹19581.00
Product Attributes
Type
Type
Capacitance
Tolerance
Voltage - Rated
ESR (Equivalent Series Resistance)
Lifetime @ Temp.
Max Operating Temperature
Ratings
Applications
Ripple Current (AC)
Ripple Current @ High Frequency
Size / Dimension
Height - Seated (Max)
Surface Mount Land Size
Mounting Type
Case/Package
Description
Polymer
100 µF
±20%
25 V
36mOhm
2000 Hrs @ 125°C
-55°C ~ 125°C
AEC-Q200
Automotive
62.75 mA @ 120 Hz
1.255 A @ 100 kHz
0.248" Dia (6.30mm)
0.236" (6.00mm)
0.260" L x 0.260" W (6.60mm x 6.60mm)
Surface Mount
Radial, Can - SMD
