UC3843AN
Manufacturer
Texas Instruments
Description
Switching Controller, Current-mode, 1A, 500kHz Switching Freq-Max, BIPolar, PDIP8
Datasheet
DownloadProduct Attributes
Type
Case/Package
Duty Cycle
Fall Time
Frequency
Height
Input Current
Lead Free
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Duty Cycle
Max Frequency
Max Input Voltage
Max Operating Temperature
Max Output Current
Max Power Dissipation
Max Supply Voltage
Min Operating Temperature
Min Supply Voltage
Nominal Input Voltage
Number of Channels
Number of Outputs
Number of Pins
Output Current
Output Type
Output Voltage
Power Dissipation
Quiescent Current
Radiation Hardening
REACH SVHC
Rise Time
RoHS
Schedule B
Switching Frequency
Termination
Thickness
Topology
Weight
Width
Description
PDIP
100 %
50 ns
450 kHz
5.08 mm
11 mA
Lead Free
9.81 mm
Production (Last Updated: 2 days ago)
ACTIVE (Last Updated: 2 days ago)
100 %
500 kHz
25 V
70 °C
4 A
1 W
30 V
0 °C
12 V
15 V
1
1
8
1 A
TOTEM POLE
15 V
1 W
11 mA
No
No
50 ns
Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
500 kHz
Through Hole
3.9 mm
Boost, Buck, Flyback
528.605208 mg
6.35 mm
₹164.70
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹164.70
₹164.70
10
₹120.14
₹1201.39
25
₹120.12
₹3003.03
50
₹102.08
₹5103.87
100
₹96.43
₹9643.18
500
₹87.00
₹43500.93
1000
₹80.93
₹80925.35
